Telescopic Automatic Sliding Doors


    Telescopic doors offer a great benefit when space is limited.
  • By incorporating an additional sliding door active leaf,
  • a telescopic sliding door allows you to gain additional clear
  • door opening.
  • Particularly welcome in the tightest space.

    EMAIL   INQUIRY

Technical Specification

Parameter

Single Open

Dual Open

Door Leaf max Weight

2 *150 kg

4 * 100 kg

Opening Width

DW 1200—2700mm

DW 2200---3000mm

Installation Type

Surface Mounting

Motor

DC24V, 100W

Power Supply

AC90-260V, 50-60 Hz

Opening Speed

300-550mm/s (adjustable)

Closing Speed

200-500mm/s (adjustable)

Hold-open Time

1-20s (adjustable)

Hold-Close Force

>100N

Manual Pushing Force

<100N

Power Consumption

<150W

Ambient Temperature

-20+50 ℃
